抛刀岭难处理金精矿细菌氧化-提金实验研究

doi:10.11872/j.issn.1005-2518.2018.02.248

Abstract

Abstract:

Paodaoling gold mine is a typical arsenic-bearing refractory gold deposit，for its gold concentrate，combined with ore properties，the effect of biooxidation pretreatment was investigated.The experiment results showed that this kind of gold ore contains 20.30 g/t gold，3.39% arsenic，29.8% sulfur and 4.10% iron，and a 30% leaching rate of the gold concentrate can be obtained by direct cyanidation.The main metallic minerals in the gold ore are pyrite，arsenopyrite and realgar.The gangue minerals include feldspar，calcite，quartz，sericite and so on，and it belongs to the refractory gold ore.After 8 days of biooxidation process by HQ0211 bactreium，the arsenic removal rate was 46.25%.The oxidation residue contains 32.1 g/t gold and the weightloss rate was 42.53%.The gold cyanidation process of oxidation residue was conducted under ventilation conditions.The sodium cyanide was 0.1% and pH was 10.5~11.After cyaniding for 48 hours，the weight of gold ore was reduced from 300 g to 290 g，and the residue yield was 96.67%.According to the analysis results of cyanidation residue，the gold content reduced from 32.1 g/t to 2.7 g/t and the gold leaching rate was 91.59%，which was greatly improved.The consumption of sodium cyanide in cyanidation process was 13.53 kg/t.The gold cyanidation effect of Paodaoling gold mine was remarkable after pretreatment by HQ0211 bacterium，it provide reliable data for treatment process of this gold ore and provide reference for effective utilization of this kind of mineral.

Key words: refractory gold ore, bacterial oxidation, arsenopyrite, pyrite, gold concentrate, pre-treatment, gold extraction by cyanidation, Paodaoling
参考文献(References)：

CLC Number:

TF18

LI Jiafeng, YANG Hongying, TONG Linlin, JIN Zhenan, ZHANG Dengchao. Experimental Study on Bacterial Oxidation-Gold Extraction of Paodaoling Refractory Gold Concentrate[J].Gold Science and Technology, 2018, 26(2): 248-253.

References

［1］刘舒飞，李亮.中国黄金产业现状及对策建议［J］.资源与产业，2016，18（4）：98-102.
Liu Shufei，Li Liang.Situation and suggestions for China’s gold resource industry［J］.Resources and industries，2016，18（4）：98-102.
［2］张朝辉，薛伟伟，余延涛.某含砷含碳微细粒嵌布难处理金矿石选矿试验［J］.湖南有色金属，2016，32（4）：21-24.
Zhang Chaohui，Xue Weiwei，Yu Yantao.Mineral processing investigation of the arsenic and carbon bearing micro-fine particle gold primary grain［J］.Hunan Nonferrous Metals，2016，32（4）：21-24.
［3］陈芳芳，张亦飞，薛光.黄金冶炼生产工艺现状及发展［J］.中国有色冶金，2011，40（1）：11-18.
Chen Fangfang，Zhang Yifei，Xue Guang.Status and development of production technology of gold smelting［J］.China Nonferrous Metallurgy，2011，40（1）：11-18.
［4］杨洪英，杨立，赵玉山，等.难处理金矿石中硫化物细菌氧化的活性序列［J］.有色金属，2002，54（2）：42-44.
Yang Hongying，Yang Li，Zhao Yushan，et al.Active alignment of sulphide minerals biooxidized by thiobacillus ferrooxidans［J］.Nonferrous Metals，2002，54（2）：42-44.
［5］王帅，李超，李宏煦.难浸金矿预处理技术及其研究进展［J］.黄金科学技术，2014，22（4）：129-134.
Wang Shuai，Li Chao，Li Hongxu.Research progress of pretreatment technologies of refractory gold ores［J］.Gold Science and Technology，2014，22（4）：129-134.
［6］杨洪英，范金，崔日成，等.难处理高砷金矿的细菌氧化—提金研究［J］.贵金属，2009，30（3）：1-3.
Yang Hongying，Fan Jin，Cui Richeng，et al.Study on bacterial oxidation-extraction gold of refractory gold ore［J］.Precious Metal，2009，30（3）：1-3.
［7］ Morin D，Lips A，Pinches T，et al.BioMinE-Integrated project for the development of biotechnology for metal-bearing materials in Europe［J］.Hydrometallurgy，2006，83（1/2/3/4）：69-76.
［8］ Demergasso C S，Galleguillos P A，Escudero L V，et al.Molecular characterization of microbial populations in a low-grade copper ore bioleaching test heap［J］.Hydrometallurgy，2005，80（4）：241-253.
［9］李宏煦，王淀佐.生物冶金中的微生物及其作用［J］.有色金属，2003，55（2）：58-63.
Li Hongxu，Wang Dianzuo.Review of investigation on microorganism behaviours in ore bio-leaching［J］.Nonferrous Metals，2003，55（2）：58-63.
［10］ Bulaev A， Kanayeva Z K，Muravyov M I，et al.Column bioleaching of refractory gold ores［J］.Advanced Materials Research，2015，1130：459-462.
［11］黄怀国，张卿，林鸿汉.难选冶金矿提取工艺工业应用现状［J］.黄金科学技术，2013，21（1）：71-77.
Huang Huaiguo，Zhang Qing，Lin Honghan.Research and application status of extraction technology for the refractory gold ore［J］.Gold Science and Technology，2013，21（1）：71-77.
［12］ Nestor D，Valdivia U，Chaves A P.Mechanisms of bioleaching of a refractory mineral of gold with Thiobacillus ferrooxidans［J］.International Journal of Mineral Processing，2001，62（1）：187-198.
［13］ Cui R C，Yang H Y，Zhang G P，et al.Biooxidation of high arsenic gold concentrate with arsenopyrite type［J］.Journal of Chemical Industry and Engineering，2008，59（12）：3090-3094.
［14］杨少华，杨凤丽，余新阳.难处理金矿石的细菌氧化机理及影响因素［J］.湿法冶金，2006，25（2）：57-60.
Yang Shaohua，Yang Fengli，Yu Xinyang.Fundamental and influence factors on bacterial oxidation of the refractory gold ores［J］.Hydrometallurgy，2006，25（2）：57-60.
［15］ Liu Q，Yang H Y，Tong L L，et al.Fungal degradation of elemental carbon in Carbonaceous gold ore［J］.Hydrometallurgy，2016，160（2）：90-97.
［16］佟琳琳，姜茂发，杨洪英，等.湖南某高砷难处理金精矿的细菌氧化—氰化提金实验研究［J］.贵金属，2008，29（1）：15-18.
Tong Linlin，Jiang Maofa，Yang Hongying，et al.Study on biooxidation-gold extraction by cyanidation experiment of a high arsenic refractory gold ore in Hunan Province［J］.Precious Metal，2008，29（1）：15-18.
［17］ Fomchenko N V，Muravyov M I，Kondrat’eva T F.Two-stage bacterial-chemical oxidation of refractory gold-bearing sulfidic concentrates［J］.Hydrometallurgy，2010，101（1）：28-34.
［18］段东平，周娥，陈思明，等.高砷硫金精矿提金研究［J］.有色金属（冶炼部分），2012（1）：39-41.
Duan Dongping，Zhou E，Chen Siming，et al.Investigation on gold recovery from high arsenic sulfur bearing gold concentrate［J］.Nonferrous Metals （Extractive Metallurgy），2012（1）：39-41.
［19］谢建宏，贾学国，张晓民.黄金选冶［M］.北京：冶金工业出版社，2014.
Xie Jianhong，Jia Xueguo，Zhang Xiaomin.Extractive Metallurgy of Gold［M］.Beijing：Metallurgical Industry Press，2014.
［20］富瑶，王琦，杨宇，等.毒砂和含砷金精矿对某浸矿细菌胞外多糖含量的影响［J］.现代矿业，2016（12）：47-50，55.
Fu Yao，Wang Qi，Yang Yu，et al.Influence of arsenopyrite and arsenic-bearing gold mineral on variation of polysaccharide in extracellular polymers of leaching bacteria stress［J］.Modern Mining，2016（12）：47-50，55.
［21］杨洪英，李雪娇，佟琳琳，等.高铅铜阳极泥的工艺矿物学［J］.中国有色金属学报，2014，34（1）：269-278.
Yang Hongying，Li Xuejiao，Tong Linlin，et al.Process mineralogy of high lead copper anode slime［J］.The Chinese Journal of Nonferrous Metals，2014，34（1）：269-278.
［22］ Márquez M，Gaspar J，Bessler K E，et al.Process mineralogy of bacterial oxidized gold ore in São Bento Mine（Brasil）［J］.Hydrometallurgy，2006，83（1/2/3/4）：114-123.
［23］ Aazami M，Lapidus G T，Azadeh A.The effect of solution parameters on the thiosulfate leaching of Zarshouran refractory gold ore［J］.International Journal of Mineral Processing，2014，131：43-50.
［24］ Vardanyan N S，Nagdalyan S Z.Periodic bioleaching of refractory gold-bearing pyrite ore［J］.Prikladnaia Biokhimiia I Mikrobiologiia，2009，45（4）：446-451.
［25］ Sharma V K，Sohn M.Aquatic arsenic：Toxicity，speciation，transformations，and remediation［J］.Environment International，2009，35（4）：743-759.
［26］ Kaksonen A H，Mudunuru B M，Hackl R.The role of microorganisms in gold processing and recovery——A review［J］.Hydrometallurgy，2014，142（2）：70-83.
［27］王中溪，黄怀国，熊明，等.某含铜金矿石氨氰柱浸提金试验［J］.黄金科学技术，2013，21（2）：90-93.
Wang Zhongxi，Huang Huaiguo，Xiong Ming，et al.Ammonia-cyanide column leaching of a copper bearing gold ore［J］.Gold Science and Technology，2013，21（2）：90-93.
